Scientists find a way to extract and store CO2 from vehicle exhaust

Scientists propose to capture CO2 and convert it from a gas to a liquid in a process that recovers most of the energy available onboard, such as heat
...
Representational image
Representational image

The fight against climate change has encouraged a group of researchers from Switzerland to device an ingenious method to curb CO2 emissions from commercial vehicles that run on fossil fuels.

Transportation is responsible for about 30 per cent of the total CO2 emissions in Europe, out of which 70 per cent originates from road-going vehicles. To rectify the situation, it's rather easy to switch to electric cars for personal use, but the real challenge arises when it comes to minimizing emissions from commercial vehicles, such as trucks and busses.

Also check these Vehicles

Find more Cars
Hyundai Kona Electric 2024 (HT Auto photo)
UPCOMING
BatteryCapacity Icon64.8 kWh Range Icon418 Km
₹ 25 Lakhs
Alert Me When Launched
Hyundai Kona Electric (HT Auto photo)
BatteryCapacity Icon39.2 kWh Range Icon452 km
₹ 23.79 - 23.98 Lakhs
Compare
View Offers
Odysse Electric Odysse Electric Hawk (HT Auto photo)
BatteryCapacity Icon2.96 kWh Range Icon170 Km
₹ 73,999 - 98,500
Compare
View Offers
Compare
Compare
Compare

Researchers at EPFL, Switzerland have now come up with a novel solution to this problem: capturing CO2 directly in the trucks' exhaust system and liquefying it in a box on the vehicle's roof. The liquid CO2 is then delivered to a service station, where it is turned into conventional fuel using renewable energy. The project is being coordinated by the Industrial Process and Energy Systems Engineering group, led by Francois Marechal, at EPFL's School of Engineering. The patented concept is the subject of a paper published in Frontiers in Energy Research.

Scientists propose to combine several technologies developed at EPFL to capture CO2 and convert it from a gas to a liquid in a process that recovers most of the energy available onboard, such as heat from the engine. In their study, the scientists used the example of a delivery truck.

First, the vehicle's flue gases in the exhaust pipe are cooled down and the water is separated from the gases. CO2 is isolated from the other gases (nitrogen and oxygen) with a temperature swing adsorption system, using metal-organic frameworks (MOFs) adsorbent, which is specially designed to absorb CO2. Those materials are being developed by the Energypolis team at EPFL Valais Wallis, led by Wendy Queen. Once the material is saturated with CO2, it is heated so that pure CO2 can be extracted from it. High-speed turbocompressors developed by Jurg Schiffmann's laboratory at EPFL's Neuchatel campus use heat from the vehicle's engine to compress the extracted CO2 and turn it into a liquid. That liquid is stored in a tank and can then be converted back into conventional fuel at the service stations using renewable electricity. "The truck simply deposits the liquid when filling up with fuel," says Marechal.

The whole process takes place within a capsule measuring 2 m x 0.9 m x 1.2 m, placed above the driver's cabin. "The weight of the capsule and the tank is only 7 percent of the vehicle's payload," adds Marechal. "The process itself uses little energy because all of its stages have been optimized."

The researchers' calculations show that a truck using 1 kg of conventional fuel could produce 3kg of liquid CO2 and that the conversion does not involve any energy penalty.

Only 10 per cent of the CO2 emissions cannot be recycled, and the researchers propose to offset that using biomass.

The system could theoretically work with all trucks, buses and even boats, and with any type of fuel. The advantage of this system is that, unlike electric or hydrogen-based ones, it can be retrofitted to existing trucks in order to neutralize their impact in terms of carbon emissions.

First Published Date: 26 Dec 2019, 10:00 AM IST
